Lustre is fantastic

which is why it is my framework of choice when building Asterism. I decided to build this OTP visualizer as a learning opportunity to understand how the BEAM works and supervisors and GenServers and all that jank.

Because I wanted to display information about the BEAM node itself, it made sense to server-render this Lustre project. This is achievable by using Lustre Server Components. On the BEAM node I would simply run a Mist server and serve the Lustre runtime on one hand, and handle the Lustre application state through a websocket endpoint, as is suggested in the Lustre docs. So far, nothing out of the ordinary.

I heavily recommend reading the Gnome Village article if some of the concepts I will bring up are confusing.

A little bit of foreshadowing

Every BEAM process has a sort of mailbox through which it receives messages. OTP GenServers (which are similar to Gleam Actors) enforce a looping structure where the user supplies one (or several in the case of gen servers) message handler functions. This means every message is processed sequentially within a GenServer or Gleam Actor.

Here's what Claude made to represent this process:

     CALLER                     GENSERVER (state: 4)

 +-------------+             +-------------------------+
 | call(:incr) |------------>| mailbox                 |
 +-------------+             | [ :incr ][ msg B ]      |
        |                    +-------------------------+
        |                                 |
     (waits)                              v
        |                    +-------------------------+
        |                    | handle :incr            |
        |                    | state 4 -> 5            |
        |                    +-------------------------+
        |                                 |
        |       reply: 5                  |
        |<--------------------------------+
        v                                 v
 +-------------+             +-------------------------+
 |   gets 5    |             | wait for next message   |
 +-------------+             +-------------------------+

I was just minding my business when suddenly...

Asterism builds a forest of BEAM processes currently running on the local BEAM node. I was implementing a way to identify whether a process was a supervisor or not. This is technically not a BEAM behavior, but an OTP behavior. Supervisors are part of the OTP supervisor module, and as explained above, they are a kind of GenServer with a message handler loop. They read messages sequentially.

To determine if a process is a supervisor, first I check if the process info has a supervisor signature, then I send a message to that process, asking it "Hey, are you a supervisor as specified in OTP?", and wait for a reply.

So, to check which of ALL processes are supervisors, I need to send a message to ALL processes that look like a supervisor at first glance. I was doing this in my Lustre application's init function...

... and this was a grave mistake.

I came to find out that a Lustre server component's init function will run in the mist_factory_supervisor$<id> process. This makes sense after all, since the Lustre application is initialized when I open the websocket connection, itself managed by mist.

This means that it's this same mist_factory_supervisor process that will send a message to every process that looks like a supervisor.

And of course, that means it'll send a message to itself and wait for a reply...

... and wait...

... and wait...

      SUPERVISOR              SUPERVISOR (same process)

 +------------------+        +-------------------------+
 | which_children() |------->| mailbox                 |
 +------------------+        | [ :which_children ]     |
          |                  +-------------------------+
          |                               |
       (waits)                            X  nobody free to read it
          |                               :
          |                  + - - - - - - - - - - - - +
          |                  : handle :which_children  :
          |                  : (never runs)            :
          |                  + - - - - - - - - - - - - +
          |                               :
          |      reply (never sent)       :
          |<- - - - - - - - - - - - - - - +
          v
 +------------------+
 |  waits forever   |
 | timeout=infinity |
 +------------------+

In practice the supervisor doesn't actually hang indefinitely. The BEAM detects the self-message sending and simply crashes the supervisor instead.

It will never send a reply to itself, because it's already busy handling a message. It can only reply to itself when it's done with the current message, and the current message can only continue when it gets a reply...

Chicken and egg...

This meant that whenever I was trying to scan every process and look for supervisors, I was inadventantly sending messages from a supervisor which crashed while messaging itself.

Then I got a hunch

I figured that, since mist was using a supervisor, it was possibly creating a worker for every websocket connection (I'm not 100% certain of the process granularity).

And, I thought, if my Lustre app's init function is running on the supervisor, maybe the update function would run on that worker instead. It would make sense. Why would a supervisor run the message handling loop of its workers? No, it wouldn't, and the update function certainly is part of the message handling loop.

Next question is, how do I move this entire process from the init function to the update function?

By using Lustre side-effects

Lustre Side-effects

Lustre side-effects are meant to allow for non-UI-blocking updates to your Lustre app, for instance calling an API, or to first display a loading screen while the page is being put together by the server. They work is by running a function "on the side" (whatever that means I'm not sure I'm not a JS scientist) and dispatch a message back to the update function when it's done.

At first I tried running the supervisor-checking functions in the side-effect itself, but sadly saw the same issue. It seems that a side-effect, while non-blocking for the UI, will still run within whatever process returns them, so to speak. An init function retuning a side-effect will run that side-effect in the same process as the init function itself (again, not 100% sure but it sure looked that way).

But then I realized that we're not actually interested in the non-blocking update thing. I can simply use an empty side-effect that dispatches a plain message saying "I'm done initializing, handler loop can now take over". This allows us to send a message to the update function the moment that the initialization is finished, and then the update function itself, running in the worker, can get started sending all those messages to all supervisors.

Isn't there any other way to do this?

Maybe, but I don't think so. To my knowledge, side-effects are the only way to essentially trigger something to run right after initialization from within the update function and outside the init function.

Wouldn't the worker send a message to itself as well?

If I was blindly sending messages to every process, then yes that could've been a problem. But I do have an extra filtering step before I send that message, where I check the process info for a typical supervisor signature (checking a process' info does not send a message to that process). Since the mist worker is not a supervisor, it does not have that typical supervisor signature, and will not send a message to itself.

The moral of the story

This was quite a tricky thing to troubleshoot, but in the end, this project is working. I wanted to learn about BEAM processes and OTP and messages and all of that by building Asterism, and this is one of the several instances where I hit my head against a wall and had to learn the hard way how it all works under the hood.

AI Disclosure

LLMs were used to make this blog post:

• to generate the GenServer ASCII diagrams
